Carbon Fiber Laminates

Bharat Composites CarboLam is (CFRP) laminates, and is a 0° unidirectional pultruded carbon fiber sheet with high tensile strength and high tensile modulus. This system may improve structural load carrying capacity and is design for strengthening concrete, timber, masonry, steel, and fiber-reinforced polymer structures.

PRODUCT HIGHLIGHTS
• High strength to weight ratio-provides additional strength without adding to the 'deadload' of a structure
• Small profile - does not reduce overhead clearance in buildings or parking structures cost effective design
• Lightweight-easily applied using hand application techniques
• Fast curing adhesive -quick installation avoiding costly downtime of structures or buildings

CHARACTERISTICS/ ADVANTAGES
• Non-corroding with high life expectancy
• Improves flexural strength capacity
• Excellent durability and fatigue resistance
• Unlimited lengths, no joints required
• Lightweight system reduces requirement for heavy supporting equipment and adds negligible additional load
• Pultrusion process increases density making strengthening narrow sections possible
• Thixotropic resin adhesive makes overhead working easier
• Low system thickness, simple execution of plate intersections or crossings
• Lightweight system reduces requirement for heavy supporting equipment and adds negligible additional load

USES
• Increasing the load capacity of floor slabs, beams and bridge sections for the installation of heavier machinery / to stabilize vibrating structures.
• Damage to structural elements due to Steel reinforcement corrosion / Accidents (Vehicle impact, earthquakes, fire)
• Improvement of serviceability and durability Reduced deflection and crack width/ Stress reduction in the steel reinforcement

CONSTRUCTION: Fibre orientation 0° (unidirectional pultruded carbon fiber laminate)
PACKAGING: Available in rolls 100 min (50 mm and 100mm) wide and 1.4 thick. also available 2.0 mm, 3.0 mm and customized thickness
COLOR: Black
SHELF LIFE: Bharat Composites Carbo Lam has an unlimited shelflife when kept in appropriate storage conditions
STORAGE: Store in unopened containers in a clean, dry area between 50 and 90 ° F (10 to 32 ° C) away from direct sunlight, flame, or other hazards.
